Atmega8 Microcontrollers IC 8Kbytes
Atmega8 Microcontrollers IC 8Kbytes is a low-power CMOS 8-bit microcontroller based on the AVR RISC architecture. By executing powerful instructions in a single clock cycle.
The ATmega8 achieves throughputs approaching 1 MIPS per MHz, allowing the system designer to optimize power consumption versus processing speed.
ATMega8 AVR Microcontroller is a 28-pin AVR microcontroller. Although we have many similar microcontrollers. ATmega8 AVR Microcontroller is popular because it is one of the cheapest microcontrollers and provides many features in lesser pins.
With a program memory of 8K bytes, the ATMega8L AVR Microcontroller application is very versatile. Various POWER SAVING modes can work on MOBILE EMBEDDED SYSTEMS. its compact size it can be put on many small boards. With the Watchdog timer reset under error, it can be used on systems with minimal human interference.
These features added together in one controller make the ATMega8L AVR Microcontroller popular. ATMEL ATMEGA8L-8PU has 23 programmable input/output (I/O) pins which can be used for interfacing with the external world.
It is possible to configure them as input or output by setting a particular register value through programming.
The AVR core combines a rich instruction set with 32 general-purpose working registers. All 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in one single instruction executed in one clock cycle.
Features:
- High-performance, Low-power Atmel AVR 8-bit Microcontroller
- Advanced RISC Architecture
- High Endurance Non-volatile Memory Segments
- Two 8-bit Timer/Counters with Separate Prescaler, one Compare Mode
- One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode
- Real-Time Counter with Separate Oscillator
- Three PWM Channels
- Power-on Reset and Programmable Brown-out Detection
- Internal Calibrated RC Oscillator
- External and Internal Interrupt Sources
- Five Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, and Standby
- 23 Programmable I/O Lines
- 28-lead PDIP, 32-lead TQFP, and 32-pad QFN/MLF
ATMEL ATMEGA8L-8PU AVR 8-bit 28 Pin Microcontroller Specifications:
| Manufacturer | MICROCHIP (ATMEL) |
| Type of integrated circuit | AVR microcontroller |
| EEPROM memory capacity | 512B |
| SRAM memory capacity | 1kB |
| Flash memory capacity | 8kB |
| Case | DIP28 |
| Clock frequency | 16MHz |
| Number of inputs/outputs | 23 |
| Number of PWM channels | 3 |
| Number of 8bit timers | 2 |
| Number of 16bit timers | 1 |
| Mounting | THT |
| Operating temperature | -40-85C |
| Operating frequency | 8MHz |
| Number of external interrupts | 2 |
| Number of output compare channels | 3 |
| Number of comparators | 1 |
| Number of input capture channels | 1 |
| Number of 10bit A/D converters | 6 |
| Family | ATMEGA |
| Number of capacitive channels | 12 |
| Terminal pitch | 2.54mm |
ATMEL ATMEGA8L-8PU AVR 8-bit 28 Pin Microcontroller Technical Parameters:
- Supply voltage 2.7V to 5.5V
- Flash memory 8KB
- EEPROM memory 512Bytes
- SRAM data memory 1KB
- 23 I/O pins
- 8ch x 10Bit ADC channels
- 3 timers
- 3 PWM channels
- Clock speed 8MHz
- Serial 2-Wire, SPI, USART interfaces
- 28-DIP case
ATMEL ATMEGA8L-8PU AVR 8-bit 28 Pin Microcontroller Datasheet:
ww1.microchip.com/Atmel-2486-8-bit-AVR-microcontroller-ATmega8_L_datasheet.pdf
Package:
1 x ATMEL ATMEGA8L-8PU AVR 8-bit 28 Pin Microcontroller
