PR08-2DP Inductive Proximity Sensor

~~₨999.00~~ ₨769.00

Wire type and power
DC 3-wire type 12-24VDC Sensing side diameter
M08Sensing distance 2mm
Installation Non-shield(non-flush)
Standard sensing target8x8x1mm(iron)
Response frequency1kHzCurrent specification
Current consumption: Max. 10mA
Control output PNP Normally Open Material Brass(nickel plated)
Cable Standard/material Standard cable
Protection structureIP67
Approval Body length Standard type
Environment Ambient temperature-25 to 70C, storage: -30 to 80C
Environment Ambient humidity35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)Max. 10% of sensing distance
Residual voltage Max. 2V
Weight Approx. 64g(approx. 52g)

Categories: Distance & Proximity, Sensors

Description
Reviews (0)

Inductive Proximity Sensor PR Series Cylindrical Cable 2mm PNP 10 V to 30 V

Inductive Proximity Sensor PR Series Cylindrical Cable 2mm PNP 10 V to 30 V is a sensor capable of detecting metal at a distance <= 2mm.PR8-2DP monitors metal objects: When the object is in the working range, PR8-2DP will trigger the output at ON. When the object is out of working range, PR8-2DP will enable output to be OFF.PR8-2DP is widely used in industrial measurement, control, and automation equipment.
