Graphical LCD 128×64

2,000.00 Original price was: ₨2,000.00.1,999.00Current price is: ₨1,999.00.
  • Operating Voltage is 5V
  • it is with Chinese font
  • it has a blue backlight
  • Controller used in it ST7920
  • its Size is 93x70mm
  • It displays 20 characters in 4 lines.
  • Its input voltage range is 4.5V to 5.5V.
  • The operating voltage for LCD is 5V Direct Current (DC).
  • Its interface consists of 6800 8 bit parallel.
  • Positive transflective is its display type.
  • Its backlight consists of blue and green.

Graphical LCD 128×64

Graphical LCD 128×64 supports Chinese characters, English characters, and even graphics. 128×64 Graphic LCD is very suitable for interactive work with Arduino. Graphic LCD is a framed graphical LCD . its size is 128 x 64. It has a liquid crystal display with backlight. This LCD has a very clear result with the STN type. It is with a simple command interface. Its libraries are also available below this page.

Features

  • Model: CX12864B-1 128×64
  • Controller: ST7920
  • Display color: blue white
  • External dimensions: 93.0 x 70.0 x 13.0
  • Screen size: 72.0 x 40.0
  • Other features: 5V logic power supply, parallel communication, high reliability, wide temperature range

Specifications:

  • Operating Voltage is 5V
  • it is with Chinese font
  • it has a blue backlight
  • Controller used in it ST7920
  • its Size is 93x70mm
  • It displays 20 characters in 4 lines.
  • Its input voltage range is 4.5V to 5.5V.
  • The operating voltage for LCD is 5V Direct Current (DC).
  • Its interface consists of 6800 8 bit parallel.
  • Positive transflective is its display type.
  • Its backlight consists of blue and green.

128×64 LCD Pinout

The following table describes the pinout of the 128×64 LCD Module that I have.

Pin Number Pin Name Pin Description
1 GND Ground
2 VCC Supply Voltage
3 VO Contrast Adjust
4 RS Register Select (CS in Serial)
5 RW Read / Write Control (Serial Data In)
6 E Enable (Serial CLK)
7 14 D0  D7 Data
15 PSB Interface Selection (0: Serial, 1: 8-bit/4-bit Parallel)
16 NC Not Connected
17 RST Reset
18 VOUT LCD Voltage Doubler Output
19 BLA Backlight LED Anode
20 BLK Backlight LED Cathode
