PM35S-048 Stepper Motor

Name: PM35S-048 Stepper Motor
SKU: 36452
Price: 209.00 PKR
Availability: OutOfStock

~~₨261.00~~ ₨209.00

This is high torque compact 2-2 PHASE stepper motor with 48 steps per revolution with working voltage 24v 600ma. It has enough torque to move small robots and the motor comes with gear shaft attached.

Usage/Applications

OA Equipment : Printers / Scanners
Industrial equipment: Flow control valves
Automotive : Maters / Optic axis control device
Home automation appliances like Sewing machines

Out of stock

Categories: Motors & Drivers, Stepper Motor

Description
Reviews (0)

PM35S-048 Stepper Motor

Motor Size	PM35S-048
Number of Steps per Rotation	48 (7.5deg/Step)
Drive Method	2-2 PHASE
Drive Circuit	UNIPOLAR CONST. VOLT.	BIPOLAR CHOPPER
Drive Voltage	24 [V]	24 [V]
Current/Phase		500 [mA]
Coil Resistance/Phase	50 [ohms]	6.6 [ohms]
Drive IC	2SC3346	BD63877EFV
Magnet Material	Ferrite plastic magnet (MSPL)
	Polar anisotropy ferrite sintered magnet (MS50)
	Nd-Fe-B bonded magnet (MS70)
Insulation Resistance	100M [ohms] MIN
Dielectric Strength	AC 500 [V] 1 [min]
Class of Insulation	CLASS E (except lead wire)
Operating Temp.	-10 [deg.C] – 50 [deg.C]
Storage Temp.	-30 [deg.C] – 80 [deg.C]
Operating Hum.	20 [%] RH – 90 [%] RH
