ONE WATT LED Pin Configuration
1 WATT LED (Light Emitting Diode) like any other LED has two terminals. One is POSITIVE TERMINAL and another is NEGATIVE TERMINAL.
| Pin Number | Pin Name | Description |
| 1 | Anode (Positive) | This pin is connected to Positive of power source. |
| 2 | Cathode(Negative) | This pin is connected to Negative of power source. |
Features
- Very long operating life (up to 100k hours)
- Available in Red, Yellow, Green, Blue, White
- Low voltage DC operated
- NO ULTRAVOILET radiation
- RoHS compliant — Lead-free
- Suitable for PWM, fully dimmable
- Superior ESD protection
- LAMBERTIAN radiation pattern
Electrical Characteristics
- Voltage applied between ANODE and CATHODE : 3.0 V to 3.5 V (Typical Operating Voltage : 3.3 V)
- Current through LED (Light Emitting Diode): 300mA to 350mA(350mA being absolute maximum forward current allowed through LED)
- Maximum reverse voltage between ANODE and CATHODE: 5 V
- Maximum Power dissipation: 1Watt
- Operating temperature: – 40 ºC to +80 ºC
- Operating LIFE : 100000 hours
