CD4002 NOR Gate Dual 4-Input
CD4002 NOR Gate Dual 4-Input in a cascade is called a NOR gate. The inclusive NOR (Not & OR) gate has an output that is normally at logic level 1 and only goes LOW to a logic level 0 when any of its inputs are at logic level 1. The Logic NOR Gate is the reverse or complementary form of the inclusive OR gate.
CD4002 Key Features
- Wide supply voltage range 3.0V to 15V
- Low power 10 nW (typ.)
- High noise immunity 0.45 VDD (typ.)
- Buffered Inputs and Outputs
- Standard Symmetrical Output Characteristics
- 100% Tested for Maximum Quiescent Current at 20V
- 5V, 10V and 15V Parametric Ratings
- Maximum Input Current of 1A at 18V Over Full Package-Temperature Range; 100nA at 18V and +25oC
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | Q1 | output of gate 1 |
| 2 | A2 | input 1 of gate 1 |
| 3 | B3 | input 2 of gate 1 |
| 4 | C4 | input 3 of gate 1 |
| 5 | D5 | input 4 of gate 1 |
| 6 | NC | normally closed |
| 7 | VSS | source supply |
| 8 | NC | normally closed |
| 9 | E9 | input 1 of gate 2 |
| 10 | F10 | input 2 of gate 2 |
| 11 | G11 | input 3 of gate 2 |
| 12 | H12 | input 4 of gate 2 |
| 13 | Q2 | output of gate 2 |
| 14 | VCC | Collector supply voltage |
Application
- Automotive
- Alarm system
- Data terminals
- Industrial controls
- Instrumentation
- Remote metering
- Medical Electronics
- Computers
CD4002 Datasheet
You can download the datasheet for CD4002 Dual 4-Input NOR Gate IC
