IR Proximity Sensor 0A4-1SK

IR Proximity Sensor 0A4-1SK are a popular choice for many projects that require accurate distance measurements. This IR sensor is more economical than sonar rangefinders, yet it provides much better performance than other IR alternatives. Interfacing to most microcontrollers is straightforward: the single analog output can be connected to an analog-to-digital converter for taking distance measurements, or the output can be connected to a comparator for threshold detection. The detection range of this version is approximately 4cm to 30cm (1.5 to 12).

The GP2Y0A41 uses a 3-pin JST PH connector that works with our 3-pin JST PH cables for Sharp distance sensors (not included), as shown in the upper picture on the right. These cables have 3-pin JST connectors on one end and are available with pre-crimped male pins, pre-crimped female pins, and with unterminated wires on the other end. It is also possible to solder three wires to the sensor where the connector pins are mounted (see the lower picture to the right). When looking at the back, the three connections from left to right are power, ground, and the output signal.

Features:

• Type of sensor: photoelectric
• Range : 40~300mm(1.5 to 12)
• Output configuration: Analogue voltage
• Operation mode: Diffuse-reflective
• Supply voltage: -0.3~7V DC
• Connection: S3B-PH
• Max operating current: 22mA
• Average current consumption: 12 mA
• Output voltage differential over distance range: 2.3 V (typical)
• Update period: 16.5  4 ms
• Size: 44.5 mm x 18.9 mm x 13.5 mm (1.75 x 0.75 x 0.53)
• Operating temperature: -10~60C
• Body material: Plastic
