5mm IR Infrared Transmitter and Receiver LED Tx Rx Pair Photodiode

5mm IR Infrared Transmitter and Receiver LED Tx Rx Pair Photodiode is the IR Transmitter and Receiver pair matched pair used in our IR proximity, White Line or Micro mouse sensor. It consists of a 5mm 940 nanometer wavelength high power IR LED and photodiode having a peak sensitivity at 940-nanometer wavelength.

Features:
Transmitter (Tx):

• Power: 0.1W.
• Absolute Maximum Forward Current: 50mA.
• Launch Angle (Approx): 45 Deg.
• Wavelength: 940nm.
• Typical forward voltage drop: 1.1V.
• Diameter: 5mm.

Receiver (Rx):

• Power: 0.15W.
• Maximum Current: 30mA.
• Receiving Angle (Approx): 45 Deg.
• Wavelength: 940nm.
• Typical forward voltage drop: 1.2V.
• Diameter: 5mm.

Features of IR Transmitter & Receiver Pair:

• Designed for short-distance detection.
• Enhanced sensitivity.
• Unfocused for sensing diffused surfaces.
• Often reliable.
• Cost-effective performance.

Applications of IR Transmitter & Receiver Pair:

• DIY projects.
• Robotics projects.
• Arduino projects.
• Raspberry-Pi projects.
• Electrical/Electronic projects.
