CCM5D Motor PWM Speed Controller With Digital LED Display

CCM5D Motor PWM Speed Controller With Digital LED Display available at best rates in Pakistan at Electronation Pakistan

Features

• D DC motor speed regulator controls the speed of DC motors by adjusting the pulse width modulation (PWM).
• Large-inch 3 digits LED display numbers allow viewing under the most adverse conditions.
• The display range of the 3-digit LED display is “000”-“100”.
• The adjustable speed range is 0% -100%.
• Applicable to DC motor (or DC load) within 5A and peak current of 8A.
• Merge one button. Push to close, then push to open.

Specifications

1. Suitable for motors with voltage: 12 and 24V
2. The total range of permissible tension: 6V to 30V DC
3. Output current: Rated current 5A (8A max short term)
4. PWM frequency: 16 kHz
5. Adjustable PWM duty cycle : 0% -100%
6. LED Digital display showing the duty cycle
7. The dimensions of the regulator are 7.8 x 4.2 x 2.5 cm
