W1209 LED THERMOSTAT TEMPERATURE CONTROLLER INCUBATION

Best Online Shopping Website for W1209 Temperature Controller Incubation Thermostat. Here you get W1209 Temperature Controller at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Multan, Faisalabad, and all over Pakistan. You can intelligently control power to most types of electrical devices based on the temperature sensed by the included high-accuracy NTC temperature sensor. Although this Temperature controller module has an embedded microcontroller no programming knowledge is required. 3 tactile switches allow for configuring various parameters including on & off trigger temperatures. The onboard relay can switch up to a maximum of 240V AC at 5A or 14V DC at 10A. The current temperature is displayed in degrees Centigrade via its 3-digit seven-segment display and the current relay state by an onboard LED.

Specifications Of W1209 Temperature Controller:-

1. Temperature Control Range: Minus 50 to 110 C
2. Resolution at -9.9 to 99.9: 0.1 C
3. Resolution at all other temperatures: 1 C
4. Measurement Accuracy: 0.1 C
5. Control Accuracy: 0.1 C
6. Refresh Rate: 0.5 Seconds
7. Input Power (DC): 12V
8. Measuring Inputs: NTC (10K 0.5%)
9. Waterproof Sensor: 0.5M
10. Output: 1 Channel Relay Output, Capacity: 10A
