| Attribute | Value |
| Transistor Type | PNP |
| Maximum DC Collector Current | -10 A |
| Maximum Collector Emitter Voltage | -140 V |
| Package Type | TO-3PN |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 100 W |
| Minimum DC Current Gain | 55 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 140 V |
| Maximum Emitter Base Voltage | 5 V |
| Maximum Operating Frequency | 30 MHz |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Operating Temperature | +150 °C |
| Dimensions | 19 x 15.9 x 4.8mm |
2SA1941 Bipolar Transistor
2SA1941 bipolar transistor p-n-p type transistor. Collector-Emitter Voltage: -140 V Collector-Base Voltage: -140 V Emitter-Base Voltage: -5 V Collector Current: -10 A Collector Dissipation – 100 W DC Current Gain (hfe) – 55 to 160 Transition Frequency – 30 MHz Operating and Storage Junction Temperature Range -55 to +150 ?C
