XH-M452 Digital Temperature Humidity Controller DC 12v

This XH-M452 Digital Temperature Humidity Controller for incubator has good performance and accuracy. XH-452 temp humidity controller has simple panel control, wide temperature range, simple design, elegant appearance, high mechanical strength. Thisdigital temperature and humidity controllercan be embedded in industrial equipment, convenient and fast. It can be used for hatch control, equipment cabinet, air conditioning system, temperature control protection, etc.

1. Supports heating mode and cooling mode.
2. High precision 0.1 Celsius and 0.1% RH.
3. Real-time display of temperature and humidity.
4. Custom load, arbitrarily selected.
5. Simple setting.
6. Easy installation.
7. Power-down memory function.
8. Model: XH-M452
9. Input voltage: DC 12V
10. Temperature range: -20~60 Celsius
11. Humidity range: 00%-100% RH
12. Detection accuracy: 0.1 Celsius 0.1% RH
13. Detection accuracy: 0.1 Celsius
14. Sensor: 1 Meter Temperature and humidity sensor
15. Output Type: Relay Output (Switch Output)
16. Size: 65x55x28mm

Temperature Control:

1. Set Start Temperature: Long press ‘Temperature +’ to set start temperature by key ‘Temperature +’ and ‘Temperature -’ and the display will flash. It will save automatically after 5 seconds and then display the current actual temperature.
2. Set Stop Temperature: Long press ‘Temperature -’ to set stop temperature by key ‘Temperature +’ and ‘Temperature -’ and the display will flash. It will save automatically after 5 seconds and then display the current actual temperature.

Humidity Control:

1. Set Start Humidity: Long press ‘Humidity+’ to set start humidity by key ‘Humidity+’ and ‘Humidity-’ and the display will flash. It will save automatically after 5 seconds and then display current actual humidity.
2. Set Stop Humidity: Long press ‘Humidity-’ to set stop humidity by key ‘Humidity+’ and ‘Humidity-’ and the display will flash. It will save automatically after 5 seconds and then display current actual humidity.

Application:

• Hatch control, Equipment cabinet, Air conditioning system, Temperature control protection, Refrigerator, Freezer, Water heater, Hosts, Printing factory, Tobacco industry, Hatchery control

Package Includes:

•   1 x XH-M452 Digital Temperature Humidity Controller
