Flame Sensor Module

Flame Sensor Module sensor which is most sensitive to a normal light is known as a flame sensor. That’s why this sensor module is used in flame alarms. This sensor detects flame otherwise wavelength within the range of 760 nm x 1100 nm from the light source. This sensor can be easily damaged to high temperature. So this sensor can be placed at a certain distance from the flame. The flame detection can be done from a 100cm distance and the detection angle will be 600. The output of this sensor is an analog signal or digital signal. These sensors are used in fire fighting robots like as a flame alarm.

What is a Flame Sensor?

A flame-sensor is one kind of detector which is mainly designed for detecting as well as responding to the occurrence of a fire or flame. The flame detection response can depend on its fitting. It includes an alarm system, a natural gas line, propane & a fire suppression system. This sensor is used in industrial boilers. The main function of this is to give authentication whether the boiler is properly working or not. The response of these sensors is faster as well as more accurate compare with a heat/smoke detector because of its mechanism while detecting the flame.

Working Principle

This sensor/detector can be built with an electronic circuit using a receiver like electromagnetic radiation. This sensor uses the infrared flame flash method, which allows the sensor to work through a coating of oil, dust, water vapor, otherwise ice.

Flame Sensor Module

The pin configuration of this sensor is shown below. It includes four pins which include the following. When this module works with a microcontroller unit then the pins are

• Pin1 (VCC pin): Voltage supply rages from 3.3V to 5.3V
• Pin2 (GND): This is a ground pin
• Pin3 (AOUT): This is an analog output pin (MCU.IO)
• Pin4 (DOUT): This is a digital output pin (MCU.IO)

Different Types

Flame-sensors are classified into four types

• IR single frequency
• IR multi-spectrum
• UV flame detectors
• UV/ IR flame detectors

Features & Specifications

The features of this sensor include the following.

• Photosensitivity is high
• Response time is fast
• Simple to use
• Sensitivity is adjustable
• Detection angle is 600,
• It is responsive to the flame range.
• Accuracy can be adjustable
• Operating voltage of this sensor is 3.3V to 5V
• Analog voltage o/ps and digital switch o/ps
• The PCB size is 3cm X 1.6cm
• Power indicator & digital switch o/p indicator
• If the flame intensity is lighter within 0.8m then the flame test can be activated, if the flame intensity is high, then the detection of distance will be improved.
