- STM32F429IGT6:the high performance STM32 MCU which features:
- Core: Cortex-M4 32-bit RISC
- Feature: single-cycle DSP instructions
- Operating Frequency: 180MHz, 225 DMIPS/1.25 DMIPS/MHz
- Operating Voltage: 1.8V-3.6V
- Package: LQFP176
- Memories: 1024kB Flash, 256+4kB SRAM
- MCU communication Interfaces:
- 6 x SPI, 4 x USART, 4 x UART, 2 x I2S, 1 x SAI, 3 x I2C
- 1 x FMC, 1 x SDIO, 2 x CAN
- 1 x LCD-TFT
- 1 x USB 2.0 HS/FS controller (with dedicated DMA)
- 1 x USB HS ULPI (external PHY required)
- 1 x 10/100 Ethernet MAC
- 1 x 8 to 14-bit camera interface
- AD & DA converters: 3 x AD (12-bit, 1s, shares 24 channels); 2 x DA (12-bit)
- Debugging/Programming: supports JTAG/SWD interfaces, supports IAP
- IS42S16400J: SDRAM 1 Meg Bits x 16 Bits x 4 Banks (64-MBIT)
- AMS1117-3.3: 3.3V voltage regulator
- MIC2075: onboard USB power management device
- Power supply switch, powered from 5Vin or USB connection
- Boot mode selection, for configuring BOOT0 pin
- Power indicator
- VBUS LED
- Reset button
- 8M crystal
- 32.768K crystal, for internal RTC with calibration
- JTAG/SWD interface: for debugging/programming
- USB connector, supports Device and/or Host
- MCU pins expander, VCC, GND and all the I/O pins are accessible on expansion connectors for further expansion
- 5Vin pinheader, 5V power supply is required when using USB HOST/OTG
- USB OTG/HOST jumper
- short the jumper when using USB OTG/HOST
- open the jumper to disconnect from related I/O port
- VBAT selection jumper
- short the jumper to use system power supply
- open the jumper to connect the VBAT to external power, such as battery
- VREF selection jumper
- short the jumper to connect VREF+ to VCC
- open the jumper to connect VREF+ to other custom pin via jumper wire
