Description
The HD74HC131 is a 3-to-8-line decoder. It has Address select inputs (A, B, C) and D type register. Address select data store to D-type registers, during the positive going transition of the clock pulse. Output control (G1, G2) are independent of select input and CLK input, and when G1 is low or G2 = High, all outputs are high.
Features
- High Speed Operation: tpd (CLK to Y) = 20 ns typ (CL = 50 pF)
- High Output Current: Fanout of 10 LSTTL Loads
- Wide Operating Voltage: VCC = 2 V to 6 V
- Low Input Current: 1 µA max
- Low Quiescent Supply Current: ICC (static) = 4 µA max (Ta = 25°C)
